Introduction
For an introduction to firewalls, please see
Firewall.
UFW - Uncomplicated Firewall
The default firewall configuration tool for Ubuntu is ufw. Developed to ease iptables firewall configuration, ufw provides a user friendly way to create an IPv4 or IPv6 host-based firewall. By default UFW is disabled.
Gufw is a GUI that is available as a frontend.
Basic Syntax and Examples
Default rules are fine for the average home user
When
you turn UFW on, it uses a default set of rules (profile) that should
be fine for the average home user. That's at least the goal of the
Ubuntu developers. In short, all 'incoming' is being denied, with some
exceptions to make things easier for home users.
Enable and Disable
Enable UFW
To turn UFW on with the default set of rules:
sudo ufw enable
To check the status of UFW:
sudo ufw status verbose
The output should be like this:
youruser@yourcomputer:~$ sudo ufw status verbose
[sudo] password for youruser:
Status: active
Logging: on (low)
Default: deny (incoming), allow (outgoing)
New profiles: skip
youruser@yourcomputer:~$
Note
that by default, deny is being applied to incoming. There are
exceptions, which can be found in the output of this command:
sudo ufw show raw
You can also read the rules files in /etc/ufw (the files whose names end with .rules).
Disable UFW
To disable ufw use:
sudo ufw disable
Allow and Deny (specific rules)
Allow
sudo ufw allow /
example: To allow incoming tcp and udp packet on port 53
example: To allow incoming tcp packets on port 53
example: To allow incoming udp packets on port 53
Deny
sudo ufw deny /
example: To deny tcp and udp packets on port 53
example: To deny incoming tcp packets on port 53
example: To deny incoming udp packets on port 53
Delete Existing Rule
To delete a rule, simply prefix the original rule with delete. For example, if the original rule was:
ufw deny 80/tcp
Use this to delete it:
sudo ufw delete deny 80/tcp
Services
You can also allow or deny by service name since ufw reads from /etc/services To see get a list of services:
less /etc/services
Allow by Service Name
sudo ufw allow
example: to allow ssh by name
Deny by Service Name
sudo ufw deny
example: to deny ssh by name
Status
Checking the status of ufw will tell you if ufw is enabled or disabled
and also list the current ufw rules that are applied to your iptables.
To check the status of ufw:
sudo ufw status
Firewall loaded
To Action From
-- ------ ----
22:tcp DENY 192.168.0.1
22:udp DENY 192.168.0.1
22:tcp DENY 192.168.0.7
22:udp DENY 192.168.0.7
22:tcp ALLOW 192.168.0.0/24
22:udp ALLOW 192.168.0.0/24
if ufw was not enabled the output would be:
sudo ufw status
Status: inactive
Logging
To enable logging use:
sudo ufw logging on
To disable logging use:
sudo ufw logging off
Advanced Syntax
You can also use a fuller syntax, specifying the source and destination addresses, ports and protocols.
Allow Access
This section shows how to allow specific access.
Allow by Specific IP
sudo ufw allow from
example:To allow packets from 207.46.232.182:
Allow by Subnet
You may use a net mask :
sudo ufw allow from 192.168.1.0/24
Allow by specific port and IP address
sudo ufw allow from to port
example: allow IP address 192.168.0.4 access to port 22 for all protocols
Allow by specific port, IP address and protocol
sudo ufw allow from to port proto
example: allow IP address 192.168.0.4 access to port 22 using TCP
Enable PING
Note: Security by obscurity may be of very little actual benefit with modern cracker scripts. By default, UFW allows ping requests. You may find you wish to leave (icmp) ping requests enabled to diagnose networking problems.
In order to disable ping (icmp) requests, you need to edit /etc/ufw/before.rules and remove the following lines:
# ok icmp codes
-A ufw-before-input -p icmp --icmp-type destination-unreachable -j ACCEPT
-A ufw-before-input -p icmp --icmp-type source-quench -j ACCEPT
-A ufw-before-input -p icmp --icmp-type time-exceeded -j ACCEPT
-A ufw-before-input -p icmp --icmp-type parameter-problem -j ACCEPT
-A ufw-before-input -p icmp --icmp-type echo-request -j ACCEPT
or change the "ACCEPT" to "DROP"
# ok icmp codes
-A ufw-before-input -p icmp --icmp-type destination-unreachable -j DROP
-A ufw-before-input -p icmp --icmp-type source-quench -j DROP
-A ufw-before-input -p icmp --icmp-type time-exceeded -j DROP
-A ufw-before-input -p icmp --icmp-type parameter-problem -j DROP
-A ufw-before-input -p icmp --icmp-type echo-request -j DROP
Deny Access
Deny by specific IP
sudo ufw deny from
example:To block packets from 207.46.232.182:
Deny by specific port and IP address
sudo ufw deny from to port
example: deny ip address 192.168.0.1 access to port 22 for all protocols
Working with numbered rules
Listing rules with a reference number
You may use status numbered to show the order and id number of rules:
sudo ufw status numbered
Editing numbered rules
Delete numbered rule
You may then delete rules using the number. This will delete the first rule and rules will shift up to fill in the list.
sudo ufw delete 1
Insert numbered rule
sudo ufw insert 1 allow from
Advanced Example
Scenario:
You want to block access to port 22 from 192.168.0.1 and 192.168.0.7
but allow all other 192.168.0.x IPs to have access to port 22 using tcp
sudo ufw deny from 192.168.0.1 to any port 22
sudo ufw deny from 192.168.0.7 to any port 22
sudo ufw allow from 192.168.0.0/24 to any port 22 proto tcp
This puts the specific rules first and the generic second. Once a rule
is matched the others will not be evaluated (see manual below) so you
must put the specific rules first.
As rules change you may need to delete old rules to ensure that new rules are put in the proper order.
To
check your rules orders you can check the status; for the scenario the
output below is the desired output for the rules to work properly
sudo ufw status
Firewall loaded
To Action From
-- ------ ----
22:tcp DENY 192.168.0.1
22:udp DENY 192.168.0.1
22:tcp DENY 192.168.0.7
22:udp DENY 192.168.0.7
22:tcp ALLOW 192.168.0.0/24
Scenario change: You want to block access to port 22 to 192.168.0.3 as well as 192.168.0.1 and 192.168.0.7.
sudo ufw delete allow from 192.168.0.0/24 to any port 22
sudo ufw status
Firewall loaded
To Action From
-- ------ ----
22:tcp DENY 192.168.0.1
22:udp DENY 192.168.0.1
22:tcp DENY 192.168.0.7
22:udp DENY 192.168.0.7
sudo ufw deny 192.168.0.3 to any port 22
sudo ufw allow 192.168.0.0/24 to any port 22 proto tcp
sudo ufw status
Firewall loaded
To Action From
-- ------ ----
22:tcp DENY 192.168.0.1
22:udp DENY 192.168.0.1
22:tcp DENY 192.168.0.7
22:udp DENY 192.168.0.7
22:tcp DENY 192.168.0.3
22:udp DENY 192.168.0.3
22:tcp ALLOW 192.168.0.0/24
If you simply add the deny rule the allow would have been above it and been applied instead of the deny
Interpreting Log Entries
The
SPT and DPT values, along with SRC and DST values, will typically be
the values you’ll focus on when analysing the firewall logs.
Psuedo Log Entry
Feb 4 23:33:37 hostname kernel: [ 3529.289825] [UFW BLOCK] IN=eth0 OUT= MAC=00:11:22:33:44:55:66:77:88:99:aa:bb:cc:dd SRC=444.333.222.111 DST=111.222.333.444 LEN=103 TOS=0x00 PREC=0x00 TTL=52 ID=0 DF PROTO=UDP SPT=53 DPT=36427 LEN=83
Date
It's good
practice to watch the dates and times. If things are out of order or
blocks of time are missing then an attacker probably messed with your
logs.
Hostname
The server’s hostname
Uptime
The time in seconds since boot.
Logged Event
Short description of the logged event; e.g. [UFW BLOCK]
IN
If set, then the event was an incoming event.
OUT
If set, then the event was an outgoing event.
MAC
This provides a 14-byte combination of the Destination MAC, Source MAC, and
EtherType fields, following the order found in the Ethernet II header. See
Ethernet frame and
EtherType for more information.
SRC
This
indicates the source IP, who sent the packet initially. Some IPs are
routable over the internet, some will only communicate over a LAN, and
some will only route back to the source computer. See
IP address for more information.
DST
This indicates the destination IP, who is meant to receive the packet. You can use
whois.net or the cli
whois to determine the owner of the IP address.
LEN
This indicates the length of the packet.
TOS
PREC
I believe this refers to the Precedence field of the IPv4 header.
TTL
This
indicates the “Time to live” for the packet. Basically each packet will
only bounce through the given number of routers before it dies and
disappears. If it hasn’t found its destination before the TTL expires,
then the packet will evaporate. This field keeps lost packets from
clogging the internet forever. See
Time to live for more information.
ID
Not sure
what this one is, but it's not really important for reading logs. It
might be ufw’s internal ID system, it might be the operating system’s
ID.
PROTO
SPT
DPT
This
indicates the destination port. I believe this is the port, which the
SRC IP sent its IP packet to, expecting a service to be running on this
port.
WINDOW
This indicates the size of packet the sender is willing to receive.
RES
This bit is reserved for future use & is always set to 0. Basically it’s irrelevant for log reading purposes.
SYN URGP
SYN
indicates that this connection requires a three-way handshake, which is
typical of TCP connections. URGP indicates whether the urgent pointer
field is relevant. 0 means it's not. Doesn’t really matter for firewall
log reading.
Other Resources
-
The most recent syntax and manual can be retrieved by getting the
man page. Otherwise open a terminal window and type:
man ufw
Firewall - wiki homepage for firewall related documentation.
Iptables - interface to the netfilter subsystem in the Linux kernel.
-
Gufw - Graphic User Interface for UFW.
